A5 Concrete Expansion Anchor

Products / Anchorage Connectors

Product images are representative only.


A5 Concrete Expansion Anchor

New for 2023: The A5 Concrete Expansion Anchor is a popular 5,000 lb anchorage connector for concrete substrates. Its ergonomic thumb rest makes installation fast, easy, and comfortable to use. The expanded connection loop eases anchor connectivity and includes a clear view cable protection to aid during inspection.

SKU: 1400052

If known, input the specific Part Number here of a pre-configured product:



Features

  • Minimum breaking strength: 5,000 lb
  • Expanded connection loop: Provides a large opening for fast and convenient connections on the jobsite
  • Clear view cable protection: Allows for easy and visual inspection of high wear areas
  • Ergonomic thumb rest: Improves grip and comfort by eliminating pinch points with contoured geometry
  • Aluminum trigger: Aircraft grade aluminum reduces weight and enables a durable long-lasting design
  • Dual expansion shoes: Automatically expand when trigger is released for quick installation
  • Easy access labels: Keeps labels out of the way during use while remaining flexible and accessible
  • For single anchoring point applications and temporary horizontal lifeline systems.


FAQS

Yes, as long as the anchor hasn't experienced any falls and it passes inspections by a competent person in the field.

Compliance

This product meets the following regional compliance standards

  • OSHA 1910.140

  • OSHA 1926.502

  • ANSI Z359.18


Industries

This product is often used in the following industries

  • Construction
  • General Industry
